Arrows 1200mm Trekker Trainer RTF / PNP w/ Vector-AH023R-VEC

AH023P-VEC
In stock
$189.99 USD
Shipping fees will be calculated at checkout.
Version
Quantity
Secure Payment Options
PayPal
Pay Later
Apple Pay

Available payment methods may vary by location, device, and order details.

Free Shipping Over $99
30 Day Return
90 Day Warranty

Overview

The Arrows Trekker 1200mm is a beginner-oriented high-wing aircraft offered in RTF and PNP variants. Its ultralight EPO airframe, large wing area and low wing loading support lift and controllability at slower speeds.

Key Features

  • High-wing configuration with large wing area and low wing loading.
  • Ultralight EPO foam airframe.
  • Fixed tricycle landing gear for directional ground handling.
  • Aluminum-plate main landing gear shaped to absorb landing loads.
  • RTF and PNP completion choices under one shared product.

Key Specs

Wingspan
1200 mm (47.2 in)
Length
950 mm (37.4 in)
Wing Area
25 dm² (387 in²)
Skill Level
Beginner

What's Included

  • Arrows Trekker 1200mm airframe
  • Installed 3136-KV1200 motor, 20A ESC and five servos
  • Fixed tricycle landing gear
  • Product manual
  • RTF includes the transmitter, receiver/flight-control equipment and flight-power items specified for that package.
  • PNP requires a compatible transmitter, receiver, 11.1V 1300mAh 25C LiPo battery and charger.

Feature Highlights

High-Wing Flight Profile
High-Wing Flight Profile

The airborne side view shows the high wing, supporting struts, nose propeller and tricycle landing gear.

Banking Flight View
Banking Flight View

The banking angle reveals the underside, wing struts, fixed gear and tail surfaces.

Underside Airframe Structure
Underside Airframe Structure

The low flight view clearly presents the wing supports and fixed tricycle gear.

Top-Side Wing Graphics
Top-Side Wing Graphics

The top-side flight view displays the full wing and tail graphics.

Grass-Field Configuration
Grass-Field Configuration

The ground view shows the cabin windows, wing struts and tricycle landing gear together.

Front Landing-Gear Stance
Front Landing-Gear Stance

The low front view shows the wide high wing, nose propeller and three-wheel layout.

Rear Fuselage Assembly
Rear Fuselage Assembly

The close-up handling image shows the removable rear fuselage section and its connection area.

Full Wing Planform
Full Wing Planform

The top ground view presents the complete wing shape and high-visibility orange-and-blue trim.

Low Grass Pass
Low Grass Pass

The Trekker is shown flying low over grass with its tricycle landing gear extended.

Specifications

Wing Loading40 g/dm² (0.08 oz/in²)
Center of Gravity50–60 mm from leading edge
Motor3136-KV1200 brushless
ESC20A; XT60 connector
Propeller10 × 5
ServosFour 9g servos and one 9g 54-degree servo
Landing GearFixed tricycle gear
Required Battery11.1V 1300mAh 25C
ControlsAilerons, elevator and rudder
FlapsNo
MaterialEPO foam
Build Time15 minutes

Completion Guide

In the Box

  • RTF Includes the transmitter, receiver/flight-control equipment and flight-power items specified for that package.
  • PNP Requires a compatible transmitter, receiver, 11.1V 1300mAh 25C LiPo battery and charger.
  • Choose the completion level that matches your radio and flight-power equipment. Confirm the selected RTF or PNP variant before checkout.

Parts & Accessories

Main Wing Set: TrekkerMain Wing Set: TrekkerAHAX103Add to cart
Propeller: 1200mm TrekkerPropeller: 1200mm TrekkerAHPROP017Add to cart
Rear Fuselage: TrekkerRear Fuselage: TrekkerAHAX102Add to cart
