If you use large batteries that require high charging power, the 500W Spektrum™ S1500 DC Smart Charger is up to the challenge. Compact enough to carry in a pocket or field bag, the S1500 easily goes with you to the field, track, or any place where you need to charge your LiPo and NiMH batteries.
The S1500 charger's improved, extra-precise scroll wheel interface simplifies setup. When used with Spektrum Smart LiPo batteries having IC3™ or IC5™ connectors, the S1500 also uploads specific parameters and health data from the battery's integrated memory chip and displays it on the bright LCD screen for review — giving you the information you need to evaluate your packs and make the best charging decisions.
For input power, use a Spektrum Power Supply unit (SPMXC10201, available separately) or any compatible DC power source with the included IC3 power cable adapter. The S1500 charger has a USB port, a software update port, plus a safety timer and protection against heat, reverse polarity, short circuit, over-current, and low input voltage.
| Battery Balance Connector | JST-XH |
|---|---|
| Battery Type | Smart, Non Smart |
| Product Weight | 8.5oz (240g) |
| Product Length | 3.7" (95mm) |
| Product Width | 3.8" (97mm) |
| Product Height | 1.9" (50mm) |
| Output Connector | IC3 |
| Application | Battery Charger for Electric Powered RC Vehicles and Aircraft |
| Programmable | Yes |
| Low Input Voltage Protection | Yes |
| Over Current Protection | Yes |
| Number of Output Ports | 1 |
| Part Type | Electronics |
| Short Circuit Protection | Yes |
| Cooling Method | Fan |
| Safety Timer | Yes |
| Peak Detection | Yes |
| Power (watts) | 500 - 699W |
| Technology | Smart |
| USB Power out | No |
| Thermal Protection | Yes |
| Input Voltage | 8-30V |
| Reverse Polarity Protection | Yes |
| Power Source | DC |
| Maximum Charge Rate | 15 or More Amps |
| Display | 2.4" 320x320 IPS LCD |
| Software Updates | Yes |
| LiPo Compatibility | 6S |
